Description
Features
-
High quality imaging with 2 MP, 1920 × 1080 resolution
-
2.7 mm to 13.5 mm varifocal lens
-
Up to 40 m IR distance for bright night imaging
-
One port for four switchable signals (TVI/AHD/CVI/CVBS)
-
Water and dust resistant (IP67)
Specification
Camera
-
Image Sensor: 2 MP CMOS
-
Signal System: PAL/NTSC
-
Resolution: 1920 (H) × 1080 (V)
-
Frame Rate: TVI: 1920 × 1080 @ 30 fps, 1080P @ 25 fps ; AHD: 1920 × 1080 @ 30 fps, 1080P @ 25 fps ; CVI: 1920 × 1080 @ 30 fps, 1080P @ 25 fps ; CVBS: PAL/NTSC
-
Min. Illumination: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
-
Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
-
Lens: 2.7 mm to 13.5 mm varifocal lens
-
Field Of View: Horizontal FOV: 100° to 30°, vertical FOV: 52° to 17°, diagonal FOV: 116° to 34.5°
-
Lens Mount: Φ14
-
Day & Night: Color & ICR
-
WDR (Wide Dynamic Range): Digital WDR
-
Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
-
AGC: Yes
-
Day/Night Mode: Auto/Color/BW (Black and White)
-
Image Mode: STD/HIGH-SAT
-
White Balance: Auto/Manual
-
AE (Auto Exposure) Mode: BLC;HLC;Global;DWDR
-
Noise Reduction: 2D DNR
-
Language: English
-
Function: Brightness;Contrast;Smart IR;Sharpness;Saturation;Mirror
