Description
Clear photopolymer resin | 405 nm LCD/DLP compatible | 0.05 mm recommended layer height | 4 s normal layer exposure | 1 kg bottle
Quick Specs
- Print with any LCD/DLP printer that uses 405 nm UV light curing technology
- Achieve fine detail with a recommended layer height of 0.05 mm
- Move quickly with a normal layer exposure duration of just 4 s
- Rely on a balanced tensile strength of 28-38 MPa and 14-18% elongation at break
- Finish parts simply with a 95% IPA wash and a 3 min UV cure
Clear Resin for Detailed LCD and DLP Prints
Anycubic High Clear Resin is a clear photopolymer UV resin made for makers who want dependable results from their resin 3D printer. It is formulated for all LCD/DLP printers that use 405 nm UV light curing technology, and its compatible wavelength range of 365-405 nm gives you flexibility across common resin setups. Supplied in a 1 kg format, it suits hobby projects, prototypes and display pieces where a clear finish matters.
Tired of Guessing Your Exposure Settings?
Dialling in a new resin can eat up time and material, so this resin comes with clear starting points. Set a recommended layer height of 0.05 mm, use a first layer exposure of 20-40 s, and run a normal layer exposure duration of 4 s. With a viscosity of 200-300 mPa·s at 25℃, the resin is specified for straightforward handling, and the printing temperature range of 20-50 ℃ gives you room to work in different environments.
Balanced Strength and Flexibility
Printed parts are specified with a hardness of 77-79 HD and a tensile strength of 28-38 MPa, so models feel firm without being fragile. An elongation at break of 14-18% and an Izod impact strength of 105 J/m add a degree of toughness for functional prototypes and handled parts. The volume shrinkage rate of 3.72-4.24% is worth keeping in mind when you design models that need to fit tightly.
Simple Post-Processing and Storage
Finishing is straightforward: wash your prints in 95% IPA for at least 3 mins, then cure them under UV light for 3 mins. Between jobs, store the resin at room temperature in a cool, dark place, protected from light, so the bottle is ready for your next print. For anyone looking for a clear 3D printer resin with published settings and mechanical data, Anycubic High Clear Resin keeps the workflow clear and repeatable.
Features
- Clear photopolymer UV resin for LCD/DLP resin 3D printers
- Compatible with all LCD/DLP printers using 405 nm UV light curing technology, with a compatible wavelength of 365-405 nm
- Recommended layer height of 0.05 mm for fine-detail prints
- Fast normal layer exposure duration of 4 s, with a 20-40 s first layer exposure
- Hardness of 77-79 HD with tensile strength of 28-38 MPa and elongation at break of 14-18%
- Izod impact strength of 105 J/m for tougher printed parts
- Viscosity of 200-300 mPa·s at 25℃ for manageable handling
- Simple post-processing: wash in 95% IPA for at least 3 mins, then UV cure for 3 mins
- Supplied as a 1 kg net weight of resin
Specifications
- Storage Temperature: Room temperature (cool, dark place, protected from light)
- Resin Type: Photopolymer Resin
- Compatible Wavelength: 365-405 nm
- Compatible Printers: All LCD/DLP printers using 405 nm UV light curing technology
- Viscosity: 200-300 mPa·s (25℃)
- Density: 1.05-1.25 g/cm³
- Hardness: 77-79 HD
- Tensile Strength: 28-38 MPa
- Elongation at Break: 14-18%
- Bending Modulus: 28-33 MPa
- Bending Strength: 700-800 MPa
- Izod Impact Strength: 105 J/m
- Volume Shrinkage Rate: 3.72-4.24%
- Recommended Layer Height: 0.05 mm
- First Layer Exposure: 20-40 s
- Normal Layer Exposure Duration: 4 s
- Printing Temperature: 20-50 ℃
- Washing Method: 95% IPA, washing duration ≥3 mins
- UV Curing Time: 3 mins
- Material Type: UV Resin
- Colour: Clear
- Net Weight: 1 kg
What's in the Box
- 1 x Anycubic High Clear Resin - Clear
Why ANYCUBIC
Choose ANYCUBIC for a 3D Printer Materials with clearly documented capabilities and specifications, making it easier to select the right fit with confidence.
